Waveshare Industrial 4G LTE Router, Support Multiple VPN Protocols, 3-Ch Ethernet Ports, WiFi High-Speed Internet Access, Dual Qualcomm Chips, Supports Multiple Mode & Frequency Bands, for Europe

Marchio: Waveshare
Nome modello: Waveshare Industrial 4G LTE Router
Caratteristica speciale: VPN support, AT command control, financial-grade data security, multi-constellation system dual-frequency positioningMostra altro
Standard di comunicazione wireless: 802.11ac
Dispositivi compatibili: personal computer, laptop, tablet, smartphone, console di gioco
Usi consigliati per il prodotto: Industriale
Tecnologia di connettività: Ethernet, Wi-Fi
Sistema operativo: RouterOS
Protocollo di sicurezza: WPA2, WPA3
Numero di porte: 5

- Support SIM8200EA-M2 core module, based on Qualcomm Snapdragon X55 platform with multi mode multi band support. Support 5G/4G/3G Internet access in various modes, which can be used in the fields of Internet of Networked Medical Treatment, Intelligent Agriculture, Smart City, Smart Robots, Security Monitoring Networking, Intelligent Bus Wifi etc
- Enjoy High Speed 5G Networking Via The Gigabit Ethernet Port Or WiFi Connection. Support AT command control (based on 3GPP TS 27.007, 27.005, and V.25TER command set). Support operator private network access, adopt financial-grade data security standards, and data transmission is stable and reliable
- Onboard 1 WAN interface and 4 LAN interfaces, the interface is 10 / 100 / 1000M Ethernet port, adaptive MDI/MDIX. Onboard 1x M.2 connector, 3x mini PCIE connectors,you can flexibly customize or upgrade the software/hardware by yourself.
- Onboard multi-function RS232/RS485 serial communication, support TCP/UDP transparent transmission, Modbus and MQTT multi-mode work. Onboard one 4G-SIM card slot and one 5G-SIM card slot, support 1.8V and 3V SIM card. Onboard 16 LED indicators for easy viewing of module operating status
- Integrated multi-constellation system dual-frequency positioning: GPS/GLONASS/BeiDou/Galileo/QZSS. Quality metal case, with multi protections like ESD protection, surge protection, electric fast pulse protection, power supply phase-reversal protection
